Function:

1. Imported electric elements, stable performance, low failure rate, adopt mature technology PLC control system, operation is stable and high-speed.

2. Adopting photoelectric detection, PLC control, software operation, conveyor belt, labeling accurately and high precision, synchronization chain mechanism ensure labeling smooth and precise calibration.

3. No objects coming not labeling, automatic alarm when leakage and without label.

4. Advanced technology of pneumatic coding system, print the batch number and expiry date clearly.

5. The whole machine use material SS304 stainless steel and anodized senior aluminum alloy material ,with high corrosion resistance and never rust;

6. Butterfly designed station, the angle of machine can be adjusted to suit for different label object shape and size.

Technical parameter:

Model	VK-TBL
Labeling speed	40-150 PCS/min
Labeling accuracy	0.6mm
Machine size	2300*750*1750mm
Label size	Width:10-150mm,Length:10-300mm
Power	220V/380V 50Hz,1200W

Device Advantages

1. Imported electric elements, stable performance, low failure rate;

2. Adopting photoelectric detection, PLC control, software operation, conveyor belt, labeling accurately and high precision;

3. Can be operated alone or contract with the production line;

4. No product not labeling, automatic alarm when leakage and without label.

5. The whole machine use material SS304 stainless steel and anodized senior aluminum alloy material ,with high corrosion resistance and never rust;

Application

Machine is suit for different kinds and size objects labeling on top and bottom surface, such as aloe jar, dental floss box or food bag or carton and so on.

Machine can be operation alone or connect with production line.

Machine can customized as requirements, longer or shorter or others.
